- Built-in Smart Charger and Single Fixed output
modes
- Reliable, Safe and Clean AC/DC Power
- Reverse Polarity, Overload and Thermal
Protection
- 2 Year Warranty
OPERATING MODES
- Fixed output mode voltage can be set
between 13.0 Vdc to 16.5 Vdc
- 3 STAGE CHARGING MODE:
This
is the Factory Settings with the Smart Charging mode
'ON' with the Output Voltages preset to 14.6V /
13.6V and 13.2V.
Since 99% of Radio operators want this
turned OFF , we do so at Bells CB before shipping
and set it to a
Fixed output
mode 14.1 VDC.
DESCRIPTION: This mode provides an automatic
charging system in three steps. 1. A fast charge to
bring a good, drained battery
back up to full
voltage rapidly ("Boost"). 2. A standard charge to
bring the battery up to a full charge at a safe rate
to prolong the life of the
battery and provide
power to run 12V lighting and appliances in the
vehicle/device ("Normal"). 3. A trickle charge to
keep the battery fresh
during times of load
inactivity ("Storage"). The charger automatically
changes modes to accommodate changes in conditions.
The chart
below is for reference only, voltages
may vary
|
